AMS1117 5V Step-Down Power Supply Module
1 sold in last 35 hours
Hurry! Over 1 people have this in their carts
... people are viewing this right now
Compare
AMS1117 5V Step-Down Power Supply Module is based on the AMS1117 5V regulator IC. It is capable of regulating a wide range of input voltage (6.0 to 12V) down to a fixed 5V output at up to 1A. Standard 0.1″ header pins provide a means of connecting to its input and output terminals. These header pins have also been conveniently placed so that the module can be inserted face down into the standard. Features : Onboard AMS1117 chip. Onboard power indicator to indicate power is turned on: Red LED. Output voltage interface, connection to facilitate the experimental. Small Compact Size, 4Pin Type, Breadboard Friendly. 2P single row pin input and output for easy connection Dual-panel design, the layout is nice Specifications: IC Chip: AMS1117 Input Voltage (V): 6.5 to 12 Output Voltage(V): 5 Max. Output Current (A): 0.8 Length (mm): 26 Width (mm): 12 Height (mm): 2 Weight (gm): 0.6 Package Includes : 1 x AMS1117 5V Step-Down Power Supply Module (Unsoldered). Note: Do not exceed absolute maximum input voltage (12.5V) or output current. Exceeding maximum specifications can result in permanent damage to this module or any connected devices. Jumper connector is not soldered.
