D3806 CNC DC Stabilized Constant Current Power Supply Adjustable Boost Module 38V 6A Charger

This is a D3806 CNC DC Stabilized Constant Current Power Supply Adjustable Boost Module 38V 6A Charger. The input voltage of this Module is about 10- 40 volt and the output voltage is about 0-38 Volt. The module has 10 groups of storage location, can store and bring up the parameters at any time. It equipped with four of the eight period LED digital tube, which can real-time display voltage, current, power, capacity and other parameters. At the same time, the machine has automatic output after electrify, automatic take turns to display parameters and other functions, you can open or close it according to the needs. Features: Digital display, convenient and easy to use Constant voltage and constant current state OUT,CV and CC indicator light Adjust output voltage and current value accurately Automatic/manual switch voltage, current, power, capacity and other parameters display It can be set whether automatic output or not after electrify It can be set whether take turns to display voltage, current, power and capacity or not after output 10 groups of storage location, free storage and bring up One key to save voltage and current value Specifications: Model: D3806 Input voltage: 10V ~ 40V Input current: 0~8A Output voltage: 0 ~ 38V Output current: 0 ~ 6A Voltage regulation/display resolution: 0.01 V Current regulation/display resolution: 0.001A minimum display resolution of power: 0.001 W minimum display resolution of capacity: 0.001AH Conversion efficiency: up to 80% output ripple: ≦50 mV Working temperature: – 40℃~ 85 ℃ Working frequency: 150 KHz Length (mm): 100 Width (mm): 80 Height (mm): 29 Weight (gm): 146 Package Includes: 1 x D3806 CNC DC Stabilized Constant Current Power Supply Adjustable Boost Module 38V 6A Charger
